Soundstream T5 - 10'' subwoofer

T5-10

10'' (25 cm) Subwoofer,
Tehonkesto: 800 Watt RMS
Voice Coil Size: 3''
Magnet Weight: 160 oz
Taajusvaste: 35-300 Hz
Impedanssi 2 + 2 Ohm
Fs: 31,4 Hz
Qts: 0,47
Qes:0,503
Qms: 5.031
Vas 13,5L
Spl: 81 db
Asennussyvyys: 168 mm
Halkaisija: 238 mm

Kotelosuositukset:

Sealed Box / Suljettu
Min. Sealed (ft.3) 0.50
Qtc 0.565
F3 (Hz) 72.62
Opt. Sealed (ft.3) 0.75
Qtc 0.512
F3 (Hz) 73.85

Max. Sealed (ft.3) 1.00
Qtc 0.485
F3 (Hz) 74.71

Ported Box
Min. Vented (ft.3) 1.25
Port (dia. x length) 3x9.5
Fb (Hz) 38.09
F3 (Hz) 32.71

Opt. Vented (ft.3) 1.50
Port (dia. x length) 4x18
Fb (Hz) 35.98
F3 (Hz) 31.03
Max. Vented (ft.3) 1.75
Port (dia. x length) 4x16.5
Fb (Hz) 33.98
F3 (Hz) 29.29
